Secure Chain
Secure Chain is an open-source initiative to strengthen the security of the Software Supply Chain (SSC).
We provide tools to:
- 📦 Analyze dependencies and configurations.
- ⚠️ Detect vulnerabilities and minimize its impact.
- 🧾 Generate security documents such as Vulnerability Exploitability eXchange (VEX) reports.
- 📊 Build and visualize dependency graphs.
How it works?
What it receives (Left side)
SecureChain begins by consuming requirement files from different software ecosystems, such as requirements.txt, package.json, or pom.xml. These files describe the dependencies that a software project relies on, serving as the raw material for the rest of the system.
How Depex and VEXGen work (Core)
At the core of SecureChain are two complementary components: Depex and VEXGen.
Depex is responsible for parsing the requirement files and resolving full dependency trees, including both direct and transitive dependencies. It also normalizes metadata across ecosystems, detects version constraints, and links packages to known vulnerabilities using precise matching logic. SecureChain ingests vulnerability data from the OSV (Open Source Vulnerability) database, which provides standardized information about known vulnerabilities, affected version ranges, and fix metadata.
VEXGen enriches this dependency data with security threat intelligence. It analyzes the timelines and scopes of vulnerabilities, identifies potentially vulnerable dependency objects of dependencies, and generates contextual insights, such as which components are affected, and whether an exploit is likely.
Together, Depex and VEXGen form the analytical engine of SecureChain, transforming static requirement files and vulnerability feeds into a structured, semantically-rich model of software dependencies and risks.
What it returns (Right side)
The output of the system is a unified knowledge graph that represents the software supply chain and its security posture. In this graph, software packages, versions, vendors, and vulnerabilities are modeled as interconnected entities. The relationships between them are encoded explicitly to allow for querying, visualization, and reasoning.
This knowledge graph enables advanced use cases such as automated supply chain impact analysis, configurations reasoning, SBOM enrichment, VEX generation, and maintainer-level risk assessments. It provides a foundation for understanding not only which components are vulnerable, but also how and why those vulnerabilities propagate through modern software stacks.
How is it made?
Secure Chain software architecture is based on microservices. The application is divided into several layers, each with a specific role and associated technologies that allow for independent scaling, maintenance, and development of functionalities. The layers that make up this architecture are briefly described below:
-
Frontend (Client Application): Built with Next.js, and served statically with Nginx, this is the user-facing layer accessed through a browser or mobile device. It sends HTTP/HTTPS requests to the backend, handles user input, and displays the results dynamically.
-
API Gateway (BFF - Backend for Frontend): Implemented with FastAPI, this gateway manages routes client requests to the appropriate microservice, and aggregates data when necessary.
-
Microservices Layer: This layer consists of three separate microservices, all built with FastAPI. Auth manages authentication. Depex extracts and analyzes software dependencies from various package managers, and reason on dependency configurations. VEXGen generates vulnerability reports in VEX format.
-
Database Layer: The microservices are powered by two databases. MongoDB stores the vulnerability data, and Neo4j stores the software supply chain graph used by our tools to compute SSC degrees and analyze dependency relationships.
Secure Chain Graph Data Structure
Secure Chain represents the software supply chain as a directed graph, where each node and relationship encodes specific knowledge about packages, their versions, and their dependencies. This model allows deep reasoning about software composition, versioning, and risk propagation. The following documentation explains the components of this graph structure as illustrated in the architecture diagram.
Node: Version
Represents a specific version of a software package. A version has the following attributes:
mean: A general risk or severity score (e.g., average CVSS score).name: Full name or label of the version (e.g.,requests).release_date: The exact date this version was published.serial_number: A sortable serial representation of the version (used to compare versions efficiently).vulnerabilities: A list of known vulnerability identifiers (e.g., CVEs or OSV IDs) that affect this version.weighted_mean: A weighted severity score, which considers not just the severity of vulnerabilities but also their reach or impact.
This node is essential for understanding when a package version became available and whether it has known vulnerabilities or risks.
Node: Dependency
Represents a software package, as it might appear in a dependency file (package.json, requirements.txt, pom.xml, sbom.json etc.). A Package has the following attributes:
import_names: The list of keywords used to import or reference the package in code (e.g.,lodash,express).moment: The point in time when this dependency was recorded or declared.name: Canonical name of the dependency.repository_url: URL to the source repository (GitHub, GitLab, Bitbucket, etc.).vendor: The organization, maintainer, or vendor responsible for the package.
Dependency nodes are the anchor points for packages in the ecosystem, and are linked to their actual released versions.
Package Types
In the Secure Chain graph, Dependency nodes can represent different ecosystems. Some examples include:
- PyPIPackage → Python ecosystem (Python Package Index)
- MavenPackage → Java ecosystem (Maven Central)
- NPMPackage → JavaScript ecosystem (Node Package Manager)
- NugetPackage → .NET ecosystem (NuGet)
- RubyGemsPackage → Ruby ecosystem (RubyGems)
- CargoPackage → Rust ecosystem (Cargo Crates)
Each of these package types follows the same general structure, but some ecosystems include additional attributes.
Special Attributes for MavenPackage:
Maven packages require additional fields to uniquely identify them:
group_id: The Maven group identifier (e.g.,org.apache.commons).artifact_id: The Maven artifact identifier (e.g.,commons-lang3).
These two fields combined (group_id:artifact_id) uniquely identify a Maven package in the ecosystem.
Relationship: :HAVE
Connects a Dependency node to a specific Version node. This relationship indicates that a given package (Dependency) has a specific published version. It allows the graph to distinguish between the concept of a software package and its concrete realizations over time.
Relationship: :REQUIRE
Connects a Version node to another Dependency node. This represents a dependency requirement (constraints) declared by a specific version of a package (parent_version_name).
